Network surveillance camera - dome - color (Day&Night) - 1920 x 1080 - audio - LAN 10/100 - MPEG-4, MJPEG, H.264 - DC 12 V / PoE
| Main Specifications | |
|---|---|
| Product Description | D-Link DCS-6113 Full HD Fixed Dome IP Camera - network surveillance camera - dome |
| Device Type | Network surveillance camera - fixed - dome |
| Audio | Yes: two-way audio capability |
| Dimensions (WxDxH) | 5.1 in x 5.1 in x 3.9 in |
| Weight | 16.65 oz |
| Connectivity Technology | Wired |
| Camera | Color - Day&Night - NTSC, PAL |
| Max Resolution | 1920 x 1080 |
| Motion Detection | Yes |
| Optical Sensor Type | CMOS - 1/2.7" |
| Minimum Illumination | 0 lux - color - F1.5 |
| Interfaces | Ethernet 10Base-T/100Base-TX |
| Voltage | DC 12 V / PoE |
| Features | IR filter, ONVIF support, Motion Detection Technology, built-in IR illuminator, temperature sensor, 1080p Full HD movie recording |
| Environmental Parameters (operating) | 32 °F - 104 °F; 0 - 90% (non-condensing) relative humidity |
| General | |
| Device Type | Network surveillance camera |
| Audio Support | Yes: two-way audio capability |
| Form Factor | Dome |
| Connectivity Technology | Wired |
| Width | 5.1 in |
| Depth | 5.1 in |
| Height | 3.9 in |
| Weight | 16.65 oz |
| Expansion / Connectivity | |
| Interfaces Details | 1 x network - Ethernet 10Base-T/100Base-TX ¦ 1 x microphone - input ¦ 1 x audio - output |
| Miscellaneous | |
| Compliant Standards | FCC Class A certified, C-Tick, ICES-003 |
| Power | |
| Power Requirements | DC 12 V / PoE - 1.25 A |
| Power Device | Power adapter - external (50/60 Hz) 5.3 watt |
| Software / System Requirements | |
| OS Required | Microsoft Windows 7, Microsoft Windows Vista / 2000 / XP |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Relative Humidity (operating) | 0 - 90% (non-condensing) |
| Camera | |
| Type | Color - Day&Night - fixed |
| Video Format | NTSC, PAL |
| Digital Video Format | MPEG-4, MJPEG, H.264 |
| Max Digital Video Resolution | 1920 x 1080 |
| Motion Detection | Yes |
| Digital Zoom | 16 |
| Minimum Illumination | 0 lux - color - F1.5 |
| Video Capture | 1920 x 1080 @ 15 fps ¦ 1280 x 720 @ 30 fps ¦ 1280 x 1024 @ 20 fps ¦ 640 x 480 @ 30 fps ¦ 320 x 240 @ 30 fps ¦ 176 x 144 @ 30 fps |
| Supported Image Formats | JPEG |
| Features | IR filter, ONVIF support, Motion Detection Technology, built-in IR illuminator, temperature sensor, 1080p Full HD movie recording |
| Image Sensor | |
| Type | CMOS 1/2.7" |
| Interfaces | |
| Network Interface | Ethernet 10Base-T/100Base-TX |
| Network Protocols | DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ICMP, SNMP, RTSP, RTP, HTTPS, UPnP, IPv4, IPv6, RTCP, PPPoE, IGMP, Samba, QOS, 3GPP/ISMA, CoS |
