Wireless access point - Wi-Fi - 2.4 GHz
| Main Specifications | |
|---|---|
| Product Description | TP-Link TL-WA801ND 300Mbps Access Point - wireless access point - Wi-Fi |
| Device Type | Wireless access point |
| Form Factor | External |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Frequency Band | 2.4 GHz |
| Included Accessories | PoE injector |
| Power Over Ethernet (PoE) Supported | PoE |
| Dimensions (WxDxH) | 6.9 in x 4.7 in x 1.1 in |
| General | |
| Device Type | Wireless access point |
| Width | 6.9 in |
| Depth | 4.7 in |
| Height | 1.1 in |
| Expansion / Connectivity | |
| Interfaces | 1 x 100Base-TX - RJ-45 |
| Miscellaneous | |
| Included Accessories | PoE injector |
| Cables Included | 1 x network cable |
| Networking | |
| Form Factor | External |
| Connectivity Technology | Wireless |
| Cable(s) / Media Type Supported | Ethernet 100Base-TX cable |
| Data Transfer Rate | 300 Mbps |
| Line Coding Format | DBPSK, DQPSK, CCK, 64 QAM, 16 QAM |
| Data Link Protocol | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Spread Spectrum Method | OFDM, DSSS |
| Frequency Band | 2.4 GHz |
| Status Indicators | Power, system, link/activity |
| Features | Wireless Distribution System (WDS) support, MIMO technology, Wi-Fi Multimedia (WMM) support, Multiple SSID support, wireless bridge mode, passive PoE supported |
| Encryption Algorithm | WPA, WPA2 |
| Authentication Method | Radio Service Set ID (SSID) |
| Compliant Standards | IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Power | |
| Power Over Ethernet (PoE) Supported | PoE |
| Power Device | External power adapter |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 10 - 90% |
| Antenna | |
| Antenna | External detachable |
| Antenna Qty | 2 |
| Directivity | Omni-directional |
| Gain Level | 4 dBi |
