Server - rack-mountable 1U - 2-way - 2 x Opteron 6172 - RAM 8 GB - no HDD - Gigabit Ethernet - monitor: none
| Main Specifications | |
|---|---|
| Type | Server - rack-mountable - system password, power-on password, diskette I/O control |
| Height (Rack Units) | 1U |
| Server Scalability | 2-way |
| Processor | 2 x AMD Opteron 6172 / 2.1 GHz (12-core) |
| Cache Memory | 24 MB L3 cache |
| Cache Per Processor | 12 MB |
| RAM | 8 GB (installed) / 256 GB (max) - DDR3 SDRAM - PC3-10600 |
| Storage Controller | RAID (SATA 3Gb/s / SAS) - PCIe 2.0 (Smart Array P410 with 512MB BBWC) |
| Hard Drive | No HDD |
| Optical Storage | No optical drive |
| Graphics Controller | Shared video memory (UMA) |
| Video Memory | 8 MB |
| Networking | GigE |
| Power | AC 120/230 V (50/60 Hz) |
| Dimensions (WxDxH) | 17.6 in x 27.6 in x 1.7 in |
| Weight | 27.4 lbs |
| General | |
| Type | Server |
| Recommended Use | Small business, corporate business |
| Product Form Factor | Rack-mountable - 1U |
| Server Scalability | 2-way |
| Expansion / Connectivity | |
| Bays | 1 (total) / 1 (free) x external 5.25" Slim Line ¦ Hot-swap |
| Slots | 1 (total) / 1 (free) x PCIe x8 - half-length, low-profile (x4 mode) ¦ 1 (total) / 1 (free) x PCIe x16 - full-length, full-height ¦ 24 DIMM 240-pin ¦ 2 (total) / 0 (free) x CPU |
| Interfaces | 1 x serial ¦ 1 x VGA ¦ 4 x USB (2 front, 2 rear) ¦ 4 x LAN (Gigabit Ethernet) |
| Miscellaneous | |
| Features | System password, power-on password, diskette I/O control |
| Compliant Standards | ACPI 2.0 |
| RAM | |
| Installed Size | 8 GB (installed) / 256 GB (max) |
| Technology | DDR3 SDRAM |
| Rated Memory Speed | 1333 MHz |
| Memory Specification Compliance | PC3-10600 |
| Form Factor | DIMM 240-pin |
| Slots | 24 (total) |
| Features | Registered |
| RAM Supported | PC3-8500 - 256 GB registered ¦ PC3-10600 - 64 GB unbuffered ¦ PC3-10600 - 192 GB registered |
| Networking | |
| Type | Integrated |
| Ethernet Ports | 4 x Gigabit Ethernet |
| Ethernet Controller | 2 x HP NC362i |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Remote Management Protocol | IPMI 2.0, SMASH CLP |
| Features | Wake on LAN (WoL), ACPI support, PXE support |
| Power | |
| Device Type | Power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Provided | 750 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 50 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 10 - 90% |
| Storage Controller | |
| Type | 1 x RAID - plug-in card - PCIe 2.0 |
| Controller Interface Type | SATA 3Gb/s / SAS |
| Storage Controller Name | Smart Array P410 with 512MB BBWC |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 10, RAID 50 |
| Buffer Size | 512 MB |
| Cache Memory | |
| Installed Size | L3 cache - 24 MB |
| Cache Per Processor | 12 MB |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Type | Integrated |
| Graphics Processor | Shared video memory (UMA) |
| Video Memory | 8 MB |
| Max Allocated RAM Size | 32 MB |
| Video Interfaces | VGA |
| Operating System / Software | |
| OS Certified | SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, SunSoft Solaris 10 |
| Hard Drive | |
| Type | No HDD |
| Dimensions & Weight | |
| Width | 17.6 in |
| Depth | 27.6 in |
| Height | 1.7 in |
| Weight | 27.4 lbs |
| Processor / Chipset | |
| CPU | AMD Opteron 6172 |
| Clock Speed | 2.1 GHz |
| Number of Cores | 12-core |
| 64-bit Computing | Yes |
| CPU Qty | 2 |
| Max CPU Qty | 2 |
| CPU Upgradability | Upgradable |
| Chipset Type | AMD SR5670/SP5100 |
