Storage enclosure - 3.5" - SATA 6Gb/s - USB 3.0 - for P/N: PEXUSB3S24, PEXUSB3S44V, ST7300USBME, SVA12M2NEUA, SVA12M5NA, USB3SMDOCK4K
| Main Specifications | |
|---|---|
| Product Description | Startech 3.5in USB 3.0 SATA External Hard Drive Enclosure w/ Fan - storage enclosure - SATA 6Gb/s - USB 3.0 |
| Device Type | Storage enclosure - external |
| Bus Type | USB 3.0 |
| Expansion Bays | 1 x internal - 3.5" |
| Hard Drive Form Factor Compatibility | 3.5" |
| Interface | SATA 6Gb/s |
| Supported Devices | Hard drive |
| System Requirements | Linux, Microsoft Windows Server 2008 R2, Apple MacOS X 10.4 - 10.6, Microsoft Windows Vista (32/64 bits), Microsoft Windows 7 (32/64 bits), Microsoft Windows XP (32/64 bits), Microsoft Windows Server 2003 (32/64-bits), Windows 8 (32/64 bits) |
| Dimensions (WxDxH) | 5.6 in x 7.1 in x 2 in |
| Weight | 20.46 oz |
| Manufacturer Warranty | 2-year warranty |
| Designed For | P/N: PEXUSB3S23, PEXUSB3S24, PEXUSB3S25, PEXUSB3S42V, PEXUSB3S44V, PEXUSB3S4V, ST7300USBME, SVA12M2NEUA, SVA12M5NA, USB3SAB1, USB3SMDOCK4K |
| General | |
| Device Type | Storage enclosure - external |
| Hard Drive Form Factor Compatibility | 3.5" |
| Host Bus | USB 3.0 |
| Expansion / Connectivity | |
| Bays | 1 x internal - 3.5" |
| Interfaces | 1 x SATA 6Gb/s |
| Connections | 1 x USB 3.0 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Features | Tested with up to 4TB 5400 RPM hard drives |
| Compliant Standards | Plug and Play |
| Software / System Requirements | |
| OS Required | Linux, Microsoft Windows Server 2008 R2, Apple MacOS X 10.4 - 10.6, Microsoft Windows Vista (32/64 bits), Microsoft Windows 7 (32/64 bits), Microsoft Windows XP (32/64 bits), Microsoft Windows Server 2003 (32/64-bits), Windows 8 (32/64 bits) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 140 °F |
| Humidity Range Operating | 10 - 90% |
| Storage Controller | |
| Interface | SATA 6Gb/s |
| Supported Devices | Hard drive |
| Processor | ASMedia ASM1051 |
| Dimensions & Weight | |
| Width | 5.6 in |
| Depth | 7.1 in |
| Height | 2 in |
| Weight | 20.46 oz |
| Compatibility Information | |
| Designed For | P/N: PEXUSB3S23, PEXUSB3S24, PEXUSB3S25, PEXUSB3S42V, PEXUSB3S44V, PEXUSB3S4V, ST7300USBME, SVA12M2NEUA, SVA12M5NA, USB3SAB1, USB3SMDOCK4K |
