Hub - 2 x serial - desktop
| Main Specifications | |
|---|---|
| Product Description | Black Box RS-232 Data Sharer - hub - 2 ports |
| Device Type | Hub - 2 ports |
| Subtype | Serial |
| Ports | 2 x serial |
| Features | Full duplex capability |
| Power | AC 120 V (60 Hz) |
| Dimensions (WxDxH) | 8.1 in x 11.3 in x 2.5 in |
| Weight | 2.43 lbs |
| General | |
| Device Type | Hub - 2 ports |
| Enclosure Type | Desktop |
| Subtype | Serial |
| Ports | 2 x serial |
| Features | Full duplex capability |
| Status Indicators | Power, carrier detect, receive |
| Expansion / Connectivity | |
| Interfaces | Serial: 2 x RS-232C - 25 pin D-Sub (DB-25) ¦ Serial: 1 x RS-232C - 25 pin D-Sub (DB-25) |
| Miscellaneous | |
| MTBF | 180,000 hours |
| Power | |
| Power Device | External power adapter |
| Voltage Required | AC 120 V (60 Hz) |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 140 °F |
| Dimensions & Weight | |
| Width | 8.1 in |
| Depth | 11.3 in |
| Height | 2.5 in |
| Weight | 2.43 lbs |
