System bus extender - for Matrix-UPS
| Main Specifications | |
|---|---|
| Product Description | APC SmartSlot Expansion Chassis - system bus extender |
| Product Type | System bus extender |
| Dimensions (WxDxH) | 5 in x 5.2 in x 2.5 in |
| Weight | 1.98 lbs |
| Manufacturer Warranty | 2-year warranty |
| Designed For | Matrix-UPS |
| General | |
| Product Type | System bus extender |
| Width | 5 in |
| Depth | 5.2 in |
| Height | 2.5 in |
| Weight | 1.98 lbs |
| Expansion / Connectivity | |
| Expansion Slots | SmartSlot |
| Interfaces | 1 x management |
| Connections | 1 x management - RS-232 - 9 pin D-Sub (DB-9) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Cables Included | 1 x serial cable - integrated |
| Compliant Standards | FCC Class B certified, VCCI, C-Tick |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 0 - 95% |
| Min Storage Temperature | 5 °F |
| Max Storage Temperature | 149 °F |
| Max Altitude Operating | 9840 ft |
| Compatibility Information | |
| Designed For | APC Matrix-UPS |
